SourceVision

Static analysis engine that inventories files, maps imports, detects architectural zones, and catalogs React components.

What It Does

SourceVision runs a 4-phase analysis pipeline:

1. Inventory — Scan all files, classify by type and role
2. Imports — Build the dependency graph
3. Zones — Detect architectural communities via Louvain algorithm, then enrich with AI
4. Components — Catalog React components with props and usage patterns

CLI

sourcevision analyze .                    # full analysis
sourcevision analyze --fast .             # skip AI enrichment
sourcevision analyze --phase zones .      # run specific phase
sourcevision serve .                      # interactive browser viewer
sourcevision validate .                   # validate analysis output
sourcevision readiness .                  # SDLC readiness scorecard
sourcevision readiness --json .           # machine-readable score, evidence and gaps
sourcevision export-pdf .                 # export analysis as PDF report
sourcevision pr-markdown .                # regenerate PR markdown summary
sourcevision git-credential-helper .      # interactive GitHub credential setup
sourcevision reset .                      # clear analysis data
sourcevision workspace .                  # aggregate multiple repos into unified view
sourcevision mcp .                        # start MCP server (stdio)
sourcevision pack add java                # install a language pack (java, go, sql, terraform)
sourcevision pack add                     # install every pack the project lists (sourcevision.packs)
sourcevision pack list                    # each pack: installed, resolved, missing or refused; listed packs marked
sourcevision pack remove java             # remove a pack from the pack directory
sourcevision pack bundle java             # archive the pack and its dependencies for offline use
sourcevision pack add java --from <file> --sha256 <hex>  # verify and install a bundle with no network

The sv command is an alias for sourcevision.

Language packs other than the default Go pack are opt-in. sv pack add <lang> runs this command (--dry-run prints it):

npm install --ignore-scripts --no-audit --no-fund --prefix <ndx home>/packs/<sourcevision version> @n-dx/lang-<lang>@<sourcevision version>

It then loads the pack and fails if it is of another version or will not load. Analysis looks in that directory before module resolution. A missing or mismatched pack never fails analysis; its notice names ndx sv pack add <lang>.

For a machine with no registry access, run sv pack bundle <lang> [--out <file>] on a connected machine with the same sourcevision version. It installs the pack into a temporary prefix and writes one .tgz (default n-dx-lang-<lang>-<version>.tgz) holding the pack, its dependencies and a manifest; grammars are WebAssembly, so a bundle serves every platform. It prints the bundle's SHA-256 and writes it to <file>.sha256. On the offline machine, sv pack add <lang> --from <file> --sha256 <hex> refuses the bundle unless its SHA-256 is <hex>, before reading it; then it refuses a bundle of another pack or version, replaces the installed copies of the pack and its dependencies and loads the pack, with no npm call.

A bundle is trusted like any npm tarball. No npm call is not no code: to validate a bundle, add --from imports its entry module from a staging directory, running its top level before anything is installed, so only add bundles from a trusted source. Its manifest is written by whoever made it, so reading the manifest is not verification: the hash is. Send the hash that bundle printed by a channel separate from the bundle, and pass it as --sha256. Without --sha256, add --from checks <file>.sha256 when it sits beside the bundle and says so; that catches a damaged copy, not a tampered one, which can carry a matching .sha256. With neither, it prints the bundle's hash and says the bundle was not verified.

A project can list the packs it wants in its config file (.n-dx.json, or .ndx/config.json), by editing it; ndx config does not set the key:

{ "sourcevision": { "packs": ["java", "go"] } }

sv analyze then reports, once per pack, a listed pack that is missing or refused (naming ndx sv pack add <lang>), even before the project has files of that language, and once for any id that is not a known pack. The list changes nothing else: what is analysed, and its output, are the same as with no list. sv pack add with no language installs each listed pack that is not already found (and says so when the list is empty or absent), and sv pack list marks the listed packs.

Pack installation internals

sv pack (src/cli/commands/pack.ts, reached as ndx sv pack …) manages the pack directory for every pack in INSTALLABLE_PACKS (java, go, terraform, python, sql; only KNOWN_PACKS, all but sql, are analyzed with today). npm never runs lifecycle scripts: no pack needs one (grammars are prebuilt WASM), and a script anywhere in the dependency tree would otherwise run with the user's privileges.

• add <lang> runs npm install --ignore-scripts --no-audit --no-fund --prefix <pack dir> @n-dx/lang-<lang>@<sourcevision version>, creating the directory, then loads the pack from it with loadPack; a mismatch, a load failure or a pack npm did not put there is an error carrying npm's output. --dry-run prints the command.
• list [--json] reports each pack as installed (pack directory), resolved (module resolution), missing or refused, with its version.
• remove <lang> runs npm uninstall --ignore-scripts --prefix; a pack found only by module resolution is left alone.

Offline, for a machine with no registry access:

• bundle <lang> [--out <file>] (connected machine) runs the same npm install into a fresh temporary prefix, loads the pack from it, writes n-dx-pack-bundle.json (pack, package, version, sourcevision version, platform: "any": grammars are WASM) and archives the whole prefix as one .tgz, default n-dx-lang-<lang>-<version>.tgz, then writes its SHA-256 to <bundle>.sha256 (sha256sum format) and prints it. The prefix is removed.
• add <lang> --from <bundle> [--sha256 <hex>] makes no npm call. It hashes the file first and refuses a mismatch with --sha256 (or, without it, with a <bundle>.sha256 beside the bundle) before parsing, extracting or importing anything; with no hash to check it prints the bundle's and says it was not verified. It then reads the manifest and refuses a bundle of another pack or version, or an archive that will not read, including one that inflates past 512 MiB (MAX_BUNDLE_BYTES), refused before any entry is parsed (a manifest that is not a JSON object is "not a pack bundle"). It extracts into .sv-pack-stage-* beside the pack directory and loads the pack from there; only then does it rename the pack's dependency closure (dependencyClosure: the pack and what its package.json files name in dependencies, optionalDependencies and peerDependencies, resolved as Node resolves them, never another pack) over the installed copies, record the pack in the pack directory's package.json and load it as add does. Anything else the bundle carries is discarded with the stage. Any failure leaves the previous install untouched.

Run one sv pack writer at a time per pack directory. npm takes no lock on a --prefix, and the pack directory is shared by every terminal, worktree and CI job on one ndx home, so add, add --from and remove hold <pack dir>.lock (PID, command and start time, published whole) for their whole run; --dry-run, list and bundle take no lock. A second writer fails at once naming the holder's PID and the lock file. A lock whose PID is dead is taken over; one that cannot be read must be deleted by hand. add --from counts a package as moved only after its rename succeeds, so a failed move never deletes a copy another writer put in place.

The archive is written and read in Node (src/cli/commands/pack-archive.ts), not by a tar process: regular files and directories only, with pax long paths. bundle never follows a symbolic link in the installed prefix; it leaves each one out and names it. Reading refuses links, bad checksums, truncation and any path that is absolute or contains ...

Output Files

All output is written to .sourcevision/:

File	Contents
manifest.json	Analysis metadata, version, timestamps
inventory.json	File listing with classifications
imports.json	Dependency graph (edges + metadata)
zones.json	Architectural zone map with cohesion/coupling metrics
components.json	React component catalog
sdlc-profile.json	SDLC practices detected, each claim tied to the file proving it
readiness.json	Readiness score computed from that profile
llms.txt	AI-readable codebase summary
CONTEXT.md	Detailed AI context document
zones/{zone-id}/	Per-zone context and summary files

Findings

SourceVision produces findings in several categories:

Type	Description	Actionable?
anti-pattern	Architectural violations (circular deps, high coupling)	Yes
suggestion	Improvement recommendations	Yes
move-file	File placement recommendations	Yes
observation	Metric descriptions ("Cohesion is 0.36")	No
pattern	Detected code patterns	No
relationship	Dependency descriptions	No

The --actionable-only flag on ndx recommend filters to only the first three types.

SDLC Readiness

ndx analyze answers "how is this code structured". sourcevision readiness answers a different question: how ready is this repository to be worked by an autonomous agent? That is effectively a CI/CD maturity reading — tests, CI, CD, rollback, migrations, feature flags, quality gates, observability, and whether the checkout's own agent configuration is safe to run.

sourcevision readiness .          # scorecard
sourcevision readiness --json .   # score, per-dimension evidence and gaps
ndx readiness .                   # same command through the orchestrator

Both artifacts are written by analyze; the command requires a prior analysis.

The scorecard is heuristic

It detects whether a practice exists and is wired up — not whether it is any good. It will tell you that tests exist, that they run in CI, and where the holes are. It will not tell you whether they assert anything useful. Reading infrastructure files is configuration review, not a pentest or a CVE scan. Treat a high score as "nothing obvious is missing", never as "this is well engineered".

Two artifacts, kept separate

Detection and judgement are deliberately not mixed, so that changing a weight cannot alter what was observed, and improving a detector cannot quietly move a score without the evidence to go with it.

Artifact	What it is
sdlc-profile.json	Deterministic record of what was detected. No LLM, no network, no clock. Every claim carries the file that proves it and a confidence of certain, likely or inferred.
readiness.json	The weighted score computed from that profile, with per-dimension evidence and gaps.

sourcevision readiness recomputes from the profile rather than printing readiness.json, so a change to the weights shows up without a re-analysis. The persisted file exists for readers that only want the headline — the dashboard's status poll, and the hub card.

A detection that is absent means the analyzer looked and found nothing. A file it recognised but could not read is reported in parseFailures with its path — never silently as absence. The scorecard keeps that distinction: when every CI file is unparseable, CI and CD still score zero, but their gap names the file and the reason and tells you to fix it rather than to add a pipeline, and sourcevision readiness lists every parse failure under "Could not parse".

Dimensions and weights

Dimension	What raises it
Testing	A test command, a known framework, and test suites on disk
CI	A parsed pipeline, jobs that run the tests, triggers on push/PR
CD	A deploy job in a pipeline, triggered automatically, to more than one named environment
Rollback	A rollback job, blue-green or canary deployment, or a down-migration path
Migrations	A migrations directory for a recognised tool
Feature flags	A feature-flag SDK dependency
Quality gates	CODEOWNERS, pre-commit hooks, merge-blocking checks
Observability	Logging, metrics, tracing or error-reporting dependencies
Agent safety	A reviewed execution config — subtractive, penalised per repo-trust finding

Weights live in one exported constant (READINESS_WEIGHTS in analyzers/readiness-score.ts) and are not restated anywhere, this table included. sourcevision readiness prints each dimension's weight beside its score, so the command is the place to read the current values.

Every gap names the evidence that would raise the score, so the output reads as a next step rather than a complaint.

Detectors

Every detector is a file-existence or file-parse check over the analyzer's own bounded walk — separate from the inventory, whose codeOnly filter drops the YAML, TOML and Dockerfiles this needs.

Section	Detected from	Confidence
Commands (test/lint/typecheck/build/deploy/migrate)	package.json scripts, Makefile targets, pyproject.toml, go.mod	certain
Test frameworks	Dependencies: vitest, jest, mocha, jasmine, playwright, cypress, ava, pytest, unittest	certain
Test suites	Test file paths, bucketed into unit / integration / e2e / contract / performance / smoke	likely
CI pipelines	.github/workflows/*.yml, .gitlab-ci.yml, .circleci/config.yml, bitbucket-pipelines.yml, Jenkinsfile	certain
CD deployments	Jobs within a parsed pipeline containing a step classified as a deploy	likely
Rollback	Not yet detected — always empty, and scores 0 with a gap saying what would move it	—
Migrations	prisma/migrations/, alembic/, db/migrate/, or a bare migrations/ directory	likely (inferred when the tool is unknown)
Feature flags	Dependencies: LaunchDarkly, Unleash, Split, Flagsmith	certain
Quality gates	CODEOWNERS, .pre-commit-config.yaml	certain
Observability	Dependencies: OpenTelemetry, Sentry, Prometheus, Pino, Winston, Bunyan, Datadog	certain
Containers	Dockerfile*, with orchestration from docker-compose*.yml, Chart.yaml or k8s/	certain
IaC	Terraform and CloudFormation resources, reusing the iso-map's existing parser	certain
Agent safety	.hench/config.json, .mcp.json and the project config, judged by @n-dx/llm-client's repo-trust	—

Known limits, stated rather than papered over:

• Rollback always scores zero today. The section is wired up and empty; no rollback detector has been written yet. That is the honest reading of an empty section, not a bug in the scorer.
• Branch protection is invisible. It lives behind the host's API, and this analysis makes no network calls — so a repository with strict required reviews scores no higher on quality gates than one without.
• A repository with no database legitimately scores zero on migrations. The gap text says so; a zero is not automatically a deficiency.
• Agent safety scores zero when no execution config exists. Defaults being in force is safe, but it is not evidence that anyone reviewed the checkout.

Viewer

sourcevision serve .    # opens browser viewer
ndx start .             # includes viewer in dashboard

The viewer provides 8 views: Overview, Imports, Zones, Files, Routes, Architecture, Problems, and Suggestions.

Zone Detection

Zones are detected using Louvain community detection on the import graph, then refined through multiple post-processing passes (small zone absorption, satellite merging, large zone splitting). AI enrichment optionally names zones, writes descriptions, and generates per-zone context files.

For a thorough explanation of the Louvain algorithm, findings system, risk assessment, and all configuration options, see SourceVision Analysis Deep Dive.

See Zone Naming Conventions for naming standards.

MCP Tools

Available via sourcevision mcp . (stdio) or ndx start . (HTTP). Claude Code prefixes these as mcp__sourcevision__{tool}; Codex uses bare names.

Tool	Description
get_overview	Project summary statistics
get_next_steps	Prioritized improvement recommendations
get_zone	Architectural zone details
get_findings	Analysis findings (anti-patterns, suggestions, observations)
get_file_info	File inventory entry, zone, and imports
search_files	Search inventory by path, role, or language
get_imports	Import graph edges
get_classifications	File archetype classifications
set_file_archetype	Override archetype classification for a file
get_route_tree	Route structure (pages, API routes, layouts)
get_readiness	SDLC readiness scorecard — the same artifact sourcevision readiness prints (heuristic)
