Rex

PRD management. The PRD is the product's requirements plus the changes being made to them; rex stores both, computes each requirement's build status, and turns codebase findings and ideas into changes. The model is explained in The PRD.

Data Model

Two layers, stored side by side in .ndx/rex/:

product/                      changes/
  Area                          Change
    Capability                    Task
      Capability (one deeper)       Subtask
    Constraint

Layer	Nodes	Each carries
Product	area, capability, constraint	A statement, and for a capability its capability criteria (the standing spec). Status (proposed, changing, met, revised, retired) and health (ok, defective) are computed, never set
Change	change, task, subtask	Title, description, acceptance criteria (done when), priority, blockedBy, a work status. A change also names what it amends (with an added, modified or removed delta) or touches, and its plannedRelease / shippedIn

Work status: pending | in_progress | completed | failing | deferred | blocked | cancelled | deleted

Priority: critical | high | medium | low

v1 projects

ndx init creates v2 projects. A v1 PRD (.rex/prd_tree/, on a project that has not yet run ndx migrate) has no product layer: it is one tree of work items, each with a level (epic › feature › task › subtask) instead of a type. The commands below say where they differ.

CLI

rex init .                           # initialize .rex/
rex status .                         # PRD tree with completion stats (v1)
rex next .                           # next actionable task
rex add "description" .              # a change in the Inbox (v1: smart add via LLM)
rex add --file=ideas.txt .           # import from file
rex add task --title="..." --criterion="..." --criterion="..." --source="..." .  # add with acceptance criteria and source
rex update <id> --status=completed . # update item
rex update <id> --criterion="..." --criterion="..." .  # replace acceptance criteria
rex update <id> --criterion= .       # clear acceptance criteria
rex update <id> --run='{"tier":"heavy","models":{"claude":"claude-opus-5-5"},"review":true}' .  # save run settings (replaces the whole block)
rex update <id> --run=null .         # clear saved run settings (--run= does the same)
rex move <id> --parent=<parent-id> . # reparent item
rex remove <id> .                    # remove item and descendants
rex reshape .                        # LLM-powered PRD restructuring
rex prune .                          # remove completed subtrees
rex restore .                        # list tree snapshots; --latest or --id=<snapshot> rolls back (v1)
rex validate .                       # check PRD integrity
rex fix .                            # auto-fix common PRD issues
rex usage .                          # token usage analytics
rex report .                         # JSON health report for CI
rex verify .                         # run acceptance criteria tests
rex analyze .                        # scan project, generate proposals
rex recommend .                      # show SourceVision recommendations
rex recommend --accept .             # add recommendations to PRD
rex reorganize .                     # detect and fix structural issues
rex health .                         # PRD structure health score
rex mcp .                            # start MCP server (stdio)

Smart Add (v1)

On a v1 PRD, rex add uses an LLM to decompose natural language descriptions into structured proposals:

rex add "Add SSO support with Google and Okta, admin config UI, audit logs" .

Produces epic/feature/task proposals with duplicate detection. When duplicates are found:

• Cancel — write nothing
• Merge — update matched items, add only non-duplicates
• Proceed — create duplicates with override markers

On a v2 PRD a description becomes one change, with no LLM call; see below.

Product Layer and Changes (v2 PRD)

On a v2 PRD (product/ and changes/) the product layer holds the standing requirements, and every add is a change:

rex add --title="Refund card payments" --criterion="A refund reaches the card" .  # a change in the Inbox, with its suggested placement
rex add task --title="Write the refund call" --parent=CH-2 .                        # a task under a change
rex product show .                                   # areas, capabilities, constraints with status and health
rex product show A1.1 .                              # one capability: statement, capability criteria, changes
rex product edit A1.1 --capability-criterion="c3: A refund reaches the card" .     # revise it; drafts a change
rex product edit A1.1 --statement="..." --editorial .                              # reword it; stays met
rex change place CH-2 .                              # the placement shortlist
rex change place CH-2 --target=A1.1 --relation=amends --capability-criterion="c3: ..." .
rex change place CH-2 --propose --type=capability --under=A1 --title="Refund by card" .   # nothing fits: propose a new node
rex change apply CH-2 .                              # apply its amendments to the product layer

rex tree-diff .                                      # what this branch changed, against the default branch
rex tree-diff --format=markdown --out=prd-diff.md .  # the pull-request comment, for a CI step to post

When either side of rex tree-diff is a v2 tree, a product map section lists the capabilities and constraints added, modified (title, statement or capability criteria) and retired beside the change list; --json carries it as map. A v1 diff has no such section. --format=markdown renders the report as host-neutral CommonMark (headings, lists and inline code only; no HTML, tables or host markers), capped at 50 entries per section. --out=<file> writes any format to a file instead of stdout, and is refused inside .rex/.

--criterion is always a work item's acceptance criteria (done when). A capability's capability criteria use --capability-criterion="<id>: <text>" (and --remove-capability-criterion=<id>), on rex product edit and rex change place only. A description passed to rex add becomes one change, without LLM decomposition. On a v1 PRD, rex add is unchanged and rex product / rex change refuse.

rex reshape, rex reorganize and rex prune restructure the change layer as they do a v1 PRD, and never write under product/. On the product layer, rex reshape drafts its accepted proposals as one change with removed and added amendments (a move is a removal plus an added copy) for rex change apply. A move or split the copy would not carry whole is not drafted and the output says why: a node with tags, notes in its body outside History, or capability requirements or dependsOn, or one another node names in dependsOn or appliesTo. A body holding only the History section that rex change apply writes does not stop a move: the retired original keeps that History, and the copy's starts with a line naming the original's id. A merge is not drafted on the same grounds when a merged node has any of these (requirements, dependsOn or appliesTo included) or another node names it, since the survivor takes over only its capability criteria. Proposals are drafted one at a time, so one that rex change apply would refuse together with those before it (a move under an area another proposal removes, say) is not drafted either, with apply's reason, and the rest still are; rex reorganize only reports; rex prune does not apply, and keeps (reporting why) an applied change that carries removed or added amendments, because product status reads a node as retired only while that change exists. On the change layer, all three skip, with the reason, a merge that would fold away any applied change (its id is what N-DX-Item trailers, rex health and its shippedIn release refer to) and a split, delete or collapse that would remove a change prune keeps; the other accepted proposals still apply, and the change-layer store refuses any other write that removes such a change.

On a v2 PRD, rex health runs the tree rules instead of scoring, and prints the reader's warnings and the landing check beside them; --format=json prints { treeRules, warnings, landings }. It exits 1 when a tree rule reports an error or the reader skipped a node (a missing or invalid root index.md, a folder with no index.md, or invalid node intent), and 0 when there are only warnings. ndx ci fails its structure-health step on that exit code and shows the error, warning and skipped-node counts. On a v1 PRD, rex health prints the score and exits 0, and ndx ci fails the step below a score of 50.

Recommend

rex recommend .                      # show findings
rex recommend --accept .             # add all to PRD
rex recommend --actionable-only .    # anti-patterns, suggestions, move-files only
rex recommend --acknowledge=1,2 .    # skip specific findings
rex recommend --acknowledge-completed .  # acknowledge completed tasks' findings

Baseline Detection (v1)

When scanning an existing codebase for the first time (empty v1 PRD), Rex detects this as a baseline scan. The LLM marks:

• Completed — functionality already implemented in the code
• Pending — gaps and improvements to build

This prevents existing code from appearing as a wall of pending tasks. On a v2 PRD, functionality the code already has belongs in the product layer as capabilities that read met.

Files

Rex's directory is .ndx/rex/ on the .ndx/ layout and .rex/ on the older one; paths below use .rex/.

File	Purpose
product/ and changes/	v2 PRD: the product layer and the change layer. Intent in each node's Markdown, tool state in each folder's committed state.yaml. See PRD Storage Layout
.rex/prd_tree/	v1 PRD folder tree: a folder per item with children, a <slug>.md file per item without
.rex/config.json	Project configuration
.rex/execution-log.jsonl	Execution history (append-only, auto-rotated at 1 MB)
.rex/workflow.md	Human-readable workflow state
.rex/acknowledged-findings.json	Acknowledged SourceVision findings
.rex/pending-proposals.json	Proposals awaiting acceptance
.rex/archive.json	Items removed by prune, reshape and reorganize (audit only; no command restores from it)
.rex/.backups/	v1 tree snapshots taken before add and reshape; rex restore rolls back to one

MCP Tools

Available via rex mcp . (stdio) or ndx start . (HTTP). Claude Code prefixes these as mcp__rex__{tool}; Codex uses bare names. The stdio server follows the client's MCP roots, so a worktree session writes its own tree; get_capabilities reports the resolved workspace (source, projectDir, refused). See MCP integration.

Tool	Description
get_product	v2: the product layer: areas with counts by default, one area's nodes with computed status and health with area, every area with full
get_capability	v2: one capability or constraint with its capability criteria and the changes on it
place_change	v2: a change's placement shortlist, record a placement (touches or amends), or propose a new capability or constraint
apply_change	v2: apply a change's amendments to the product layer, as a steward
get_prd_status	PRD title and stats. v2: change counts, Inbox count, product status per area, changes per release. v1: per-epic stats
get_next_task	Next actionable task based on priority and dependencies (skips tasks claimed by another worktree)
claim_task	Hold a task for this worktree so other worktrees skip it
release_task	Give back a claim without changing the task's status
update_task_status	Update item status. While a hench run in this worktree holds the task, completed is recorded for the run to apply after its test gate rather than written
add_item	Add an item: v2 type (change, task, subtask), v1 level (epic, feature, task, subtask). Optional run block of saved run settings: portable tier plus optional per-vendor models pins
edit_item	Edit item content (title, description, priority, tags, run). A run object replaces the whole saved block; null removes it
get_item	Full item details with parent chain
move_item	Reparent an item in the PRD tree
merge_items	Consolidate duplicate sibling items
get_recommendations	SourceVision-based recommendations
verify_criteria	Map acceptance criteria to test files
reorganize	Detect and fix structural issues
health	PRD structure health score
facets	List configured facets with distribution
append_log	Write structured log entry
get_token_usage	Roll up hench run token totals per PRD item
get_capabilities	Server capabilities and configuration, plus the workspace block (resolved project dir, source, refusal)
